200mV LCD Voltmeter with Annunciators - DPM 600
Save $12.10
$121.00
$108.90
Order now, stock will leave our store in the next 2-4 weeks
Email The Electric Burst Team For More Availability Information
SKU DPM 600
The DPM 600 is a 3½ digit LCD voltmeter with 12.5mm (0.5") digit height. It features 200mV d.c. full scale reading, bandgap reference,auto-zero, auto-polarity and a set of annunciators. The meter can be panel mounted using the bezel and window. Connection to the meter is via solder pads.
Features:
• 3½ Digit LCD Voltmeter
• 200mV Full Scale Reading
• Auto-zero, Auto-polarity
• Bandgap Reference
• Bezel Mounted
Specifications:
• Accuracy (overall error): 0.05 to 0.1 % (±1 count)
• Linearity: ±1count
• Sample rate: 3 samples/sec
• Operating temperature range: 0 to 50 °C
• Temperature stability: 30 ppm/°C
• Supply voltage: 5 to 9 V d.c.
• Supply current: 150 uA
• Input leakage current: 1-10 pA
Features:
• 3½ Digit LCD Voltmeter
• 200mV Full Scale Reading
• Auto-zero, Auto-polarity
• Bandgap Reference
• Bezel Mounted
Specifications:
• Accuracy (overall error): 0.05 to 0.1 % (±1 count)
• Linearity: ±1count
• Sample rate: 3 samples/sec
• Operating temperature range: 0 to 50 °C
• Temperature stability: 30 ppm/°C
• Supply voltage: 5 to 9 V d.c.
• Supply current: 150 uA
• Input leakage current: 1-10 pA
