3.5” PanelPilot Programmable TFT 4-20mA Loop Meter - SGD 35-M420
Save $28.71
$287.10
$258.39
Order now, stock will leave our store in the next 2-4 weeks
Email The Electric Burst Team For More Availability Information
SKU SGD 35-M420
The SGD 35-M420 is a programmable panel meter featuring 4-20mA analogue inputs, alarm outputs and 3.5” TFT colour touchscreen display. Configured using the free PanelPilot M Software, choose from an ever-increasing number of configurations including bar-graph, tank level, analogue style and trend graphs. Then customise colours, text labels, units and input scaling before uploading to a display via USB.
Specifications:
- Display: 3.5” colour TFT screen
- Resolution: 320 x 240 pixel (QVGA)
- Operating Voltage: 4 to 30V d.c.
- Measurement range: 4 to 20mA
- Viewing Area: 70.1 mm (2.8”) x 52.7 mm (2.1”)
Specifications:
- Display: 3.5” colour TFT screen
- Resolution: 320 x 240 pixel (QVGA)
- Operating Voltage: 4 to 30V d.c.
- Measurement range: 4 to 20mA
- Viewing Area: 70.1 mm (2.8”) x 52.7 mm (2.1”)
