WR-3 Plus Wireless Anemometer Kit Product code: WR3PKit
Order now, stock will leave our store in the next 2-4 weeks
Email The Electric Burst Team For More Availability Information
- Max 500m ultra-long wireless transceiver
- Audible & visual wind speed alarm
- Data recording up to 1 year
- Wind speed, temperature, air pressure measurements
- Max 3 years sensor battery life
- IP67 waterproof & impact resistant
- Fast & secure magnetic installation kit
Functions
Instant Wind Speed Alarm: WR-3 Plus displays the live wind speed value in selectable measurement units (m/s, knots, MPH, km/hr) Users can set a wind speed warning limit on based on local operation safety standards. An audible and visual alarm will be trigger when the limit has been reached. Each sensor has a unique wireless address that can connect to several displays to notify multiple stakeholders on-site.
Data Recording: WR-3 Plus capture and storage wind speed, temperature, air pressure measurements.64MB built-in memory and outstanding battery life supports up to 1 year of continuous data recording. (based on 10s logging interval, adjustable: 2s, 5s, 10s, 1min, 5 mins, 10 mins, 60 mins)
Graphical Display: The large LCD backlit display with user-friendly interface clearly indicates live weather data in various units of measurement. Users can view hourly wind records and historical bar charts from the past 12 hours on different pages.
- Live Wind Speed
- Average Wind Speed (selectable averaging)
- Maximum Wind Speed
- Ambient Temperature
- Beaufort Bar Graph
- Wind Chil
- Atmospheric Pressure
Specifications
Wind Speed Sensor:
- Unit: m/s, knots, MPH, km/hr
- Range: 0.3 to 50 m/s
- Resolution: 0.1 m/s/0.1 knots/0.1 MPH/0.1 km/hr
- Accuracy: 2% FS
Temperature Sensor:
- Unit: C/F
- Range: -30C to 60C
- Resolution: 0.1C/0.1F
- Accuracy: 1C
Atmospheric Pressure Sensor:
- Unit: hPa/mmHg/bar
- Range: 500 to 1100 hPa
- Resolution: 1 hPa/0.1 mmHg/0.001 bar
- Accuracy: 4 hPa
Wireless Sensor:
- Frequency: 868MHz(default), 915MHz
- Distance: Max 500m* (depends on the applied environment)
- Data rate: Every 2 seconds
- Power supply: 1x 3.6V 18505 Lithium battery
- Waterproof rating: IP67
- Weight: 406g
- Dimensions: 262.5 x 183.5 x32mm
Data Logger:
- Receiver buzzer: > 80dB
- Built-in memory: 64MB
- Output: .xlxs, .xls
- Data logger" wind speed, temperature, atmospheric pressure
- Logging interval: 2s, 5s, 10s, 1min, 5 mins, 10 mins, 60 mins
- Power supply: 3x 1.5V AA battery, Micro USB port
- Dimensions: 189.6 x 75.6 x 36.3mm
- Weight: 205g
